PP compression fittings are connectors for PE pipes used in water supply systems. They are suitable for both irrigation and drinking water applications. Gaia fittings range includes a wide variety of items designed to meet the diverse needs of plant engineering and installation requirements
Standard ISO 17885 / DIN 8076
| Code | Dia | PN | Price (Pc) | Box (Pcs) | Sacks (Pcs) |
|---|---|---|---|---|---|
| 22025020 | 25×20 | 16 | 200 | 120 | |
| 22032025 | 32×25 | 16 | 120 | 90 | |
| 22040032 | 40×32 | 16 | 65 | 50 | |
| 22050040 | 50×40 | 16 | 40 | 30 | |
| 22063050 | 63×50 | 16 | 28 | 20 | |
| 22075063 | 75×63 | 16 | 20 | 14 | |
| 22090075 | 90×75 | 16 | 10 | 8 | |
| 22110075 | 110×75 | 16 | 5 | 4 | |
| 22110090 | 110×90 | 16 | 5 | 4 |
